Features

  • Unparalleled transient response
  • Aggressive aerodynamics with 7+7 splitter wheels
  • Lightweight 310s stainless steel investment cast turbine housings
  • Lightweight, Aluminium compressor covers
  • CFD driven designed housings for optimal A/R’s and flow
  • T14 Inconel turbine wheel for extreme EGT’s
  • VSR speed balanced
  • Proprietary dual ceramic bearing system
  • Integrated Iron backplate on center housing



Specifications

  • Compressor Inlet: 4″ / 101.6mm
  • Compressor Inducer: 68mm
  • Turbine Inlet: V-Band (2.25″)
  • Turbine Exducer: 70mm
  • Turbine AR: 1.07
  • Turbine Outlet: V-Band (3.00″)
  • Weight: 6.06kg / 13.3lbs
  • Horsepower Rating: 850-990HP

(TS-2-6870B-VB107E)

SKU TS-2-6870B-VB107E
Brand Turbosmart
Shipping Weight 7.0000kg
Shipping Width 0.300m
Shipping Height 0.300m
Shipping Length 0.300m
Shipping Cubic 0.027000000m3
